repair script hanging

platformio.ini

@@ -12,3 +12,6 @@
 platform = espressif8266
 board = esp12e
 framework = arduino
+
+upload_port = esp_wz_duft.local ;192.168.1.134
+upload_flags = --auth=druffmann77

src/Duftsprueher.ino

@@ -2,7 +2,8 @@
 #include <Arduino.h>
 #include <ESP8266WiFi.h>      //ESP library from http://github.com/esp8266/Arduino
 #include <PubSubClient.h>      // MQTT library from http://github.com/Imroy/pubsubclient
-#include "Servo.h"
+#include <Servo.h>
+#include <ArduinoOTA.h>

 extern "C" {
   #include "user_interface.h"
@@ -11,45 +12,25 @@ extern "C" {
 String esp_id = "duft";

 const char *ssid =   "iApfel";      // cannot be longer than 32 characters!
-const char *password =   "***PASSWORD***";      //
+const char *password =   "druffmann77";      //
 const char* mqtt_server = "192.168.1.5";
+const char* ota_password = "druffmann77";

 #define SERV1 12 // Pin connected to the Servomotor
 Servo s1;

 // Strings zusammen bauen
-String esp = "esp_wz" + esp_id;
+String esp = "esp_wz_" + esp_id;
 char *esp_name = &esp[0u];

-//String air_topic = "esp" + String(esp_id) + "/room";
-//const char* mqtt_air_topic = &air_topic[0u];
-const char* mqtt_air_topic = "airfresh";
+String print_topic = "airfresh";
+const char* mqtt_print_topic = &print_topic[0u];

 WiFiClient espClient;
 PubSubClient client(espClient);

-void setup() {
-  // start the serial connection
-  Serial.begin(115200);
-
-  setup_wifi();
-
-  Serial.print("Connecting to MQTT");
-  client.setServer(mqtt_server, 1883);
-  Serial.print("Connected to MQTT");
-  client.setCallback(callback);
-  client.publish("airfrash","hello world");
-  client.subscribe("airfresh");
-
-  // move servomotor to neutral position
-  s1.attach(SERV1);
-  delay(400);
-  s1.write(90);
-  delay(400);
-  s1.detach();
-}
-
 void setup_wifi() {
+  delay(10);
   WiFi.mode(WIFI_STA);
   WiFi.begin(ssid, password);
   //wifi_set_phy_mode(PHY_MODE_11G);
@@ -66,8 +47,8 @@ void setup_wifi() {

   // animate LEDs while waiting for connection
   while (WiFi.status() != WL_CONNECTED) {
+    delay(500);
     Serial.print(".");
-    delay(50);
   }

   Serial.println("");
@@ -76,30 +57,41 @@ void setup_wifi() {
   Serial.println(WiFi.localIP());
 }

-void loop() {
-  // Check WLan
-  if (WiFi.status() != WL_CONNECTED) {
-    reconnect();
+void setup() {
+  // start the serial connection
+  Serial.begin(115200);
+
+  setup_wifi();
+
+  client.setServer(mqtt_server, 1883);
+  client.setCallback(callback);
+
+  ArduinoOTA.setPassword(ota_password);
+  ArduinoOTA.setHostname(esp_name);
+  ArduinoOTA.onStart([]() {
+    String type;
+    if (ArduinoOTA.getCommand() == U_FLASH)
+      type = "sketch";
+    else // U_SPIFFS
+      type = "filesystem";
+  });
+  ArduinoOTA.begin();
+
+  // move servomotor to neutral position
+  s1.attach(SERV1);
+  s1.write(90);
+  delay(3000);
+  s1.detach();
 }

-  // Check mqtt messages
-  if (!client.connected()) {
-    reconnect();
-  }
-  client.loop();
-}
-
-// this function is called whenever a message
-// is received from Adafruit IO. it was attached to
-// the feed in the setup() function above.
 void callback(char* topic, byte* payload, unsigned int length) {
   // Zähler
    int i = 0;
    // Hilfsvariablen für die Convertierung der Nachricht in ein String
    char message_buff[100];

-   Serial.println("Message arrived: topic: " + String(topic));
-   Serial.println("Length: " + String(length,DEC));
+   //Serial.println("Message arrived: topic: " + String(topic));
+   //Serial.println("Length: " + String(length,DEC));

    // Kopieren der Nachricht und erstellen eines Bytes mit abschließender \0
    for(i=0; i<length; i++) {
@@ -109,34 +101,30 @@ void callback(char* topic, byte* payload, unsigned int length) {

    // Konvertierung der nachricht in ein String
    String msgString = String(message_buff);
-   Serial.println("Payload: " + msgString);
+   //Serial.println("Payload: " + msgString);

   // if virtual push button was pressed
   if (msgString.equalsIgnoreCase("1")){
     Serial.println("Virtual push button");
     s1.attach(SERV1);
-    delay(400);
-    s1.write(55);
+    s1.write(60);
     delay(1000);
     s1.write(90);
-    delay(1000);
+    delay(3000);
     s1.detach();
   }
+
+  client.loop();
 }

 void reconnect() {
   // Loop until we're reconnected
-  while (WiFi.status() != WL_CONNECTED) {
-    delay(500);
-    Serial.print(".");
-  }
-
   while (!client.connected()) {
     Serial.print("Attempting MQTT connection...");
     // Attempt to connect
-    if (client.connect("arduinoClient")) {
+    if (client.connect(esp_name)) {
       Serial.println("connected");
-      client.subscribe(mqtt_air_topic);
+      client.subscribe(mqtt_print_topic);
     } else {
       Serial.print("failed, rc=");
       Serial.print(client.state());
@@ -146,3 +134,12 @@ void reconnect() {
     }
   }
 }
+
+void loop() {
+  if (!client.connected()) {
+    reconnect();
+  }
+
+  client.loop();
+  ArduinoOTA.handle();
+}
